Gigabyte Brix GB-BRR5-4500

Provedení PC:Mini-PC; Využití PC:Domácnost a kancelář; Řada procesoru:AMD RYZEN 5; Výbava PC:Wi-Fi; Rozhraní:HDMI, USB 3.2, 3.5mm Jack, LAN, USB Type-C, mini DisplayPort

GB-BRR5-4500

• High Performance Ultra Compact PC (34.7 x 119.5 x 119.5 mm)
• 1 x M.2 SSD (2280) slot support PCI-e x4 /SATA
• 2 x SO-DIMM DDR4 slots support 3200Mhz, Max 64GB
• Intel WIFI6 +BT5.2
• Realtek 2.5G LAN RTL8125
• QUAD display : 2x Type C / HDMI / mDP with HDCP @4x4K/60P
• 5x USB 3.2 Gen1 Type A + 2x USB 3.2 Gen2 Type C (4F,3R)
• Realtek ALC255 Codec
• Headphone Jack
• VESA Mounting Bracket (75 x 75mm + 100 x 100mm)
• AC-DC adapter : 100-240V input, 19V/90W
• OS Support : Microsoft Windows 10 64Bit
• 1x Kensington Lock slot
• System Environment Operating Temperature: 0°C to +35°C
• System Storage Temperature: -20°C to +60°C

TECHNICAL SPECIFICATIONS

Dimensions34.7 mm x 119.5 mm x 119.5 mm (1.37" x 4.7" x 4.7") Motherboard Size105 x 110 mm CPUAMD RYZEN R5-4500U, 2.3G~4.0G Turbo, 6C/6T Core, 11MB L3 Cache

AMD Radeon GPU 1500Mhz , 15W Memory2 x SO-DIMM DDR4 slots 3200MHz

Max. 64GB LAN2.5G LAN (Realtek 8125) Wifi CardIntel WiFi6 AX200 / BT 5.2 VideoAMD Radeon™ Graphics AudioRealtek ALC255 HDMI Resolution (Max.)HDMI2.0a ws HDCP 2.2 3840x2160@60Hz Storage1 x M.2 slot (2280_storage)

PCIe Gen3 X4 /SATA Expansion Slots1 x PCIe M.2 NGFF 2230 A-E key slot occupied by the WiFi+BT card Front I/O1 x Power Button 1 x USB 3.2 type C (Gen2) w/ DP alt mode 3 x USB type A 3.2 (Gen1) 1 x head phone jack with MIC Rear I/O1 x HDMI(2.0a) 1 x mDP 1 x USB 3.2 type C (Gen2) w/ DP alt mode 2 x USB 3.2 type A (Gen 1) 1 x RJ45

• 1 x DC-In Side I/O1 x Kensington lock slotPower SupplyInput: AC 100-240V
• Output: DC 19V/4.74A, 90W Support OSWin10 64bit EnvironmentOperating Temperature 0°C to 35°C

Storage Temperature -20°C to +60°C
